Hanger Type Shot Blasting Machine

Name: Hanger Type Shot Blasting Machine
Brand: Rotofinish Blasting Equipments
Price: 450000 INR
Availability: InStock

Price 450000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Hanger Type Shot Blasting Machine Specification

Model No
Refer Rotofinish Catalogue

Control System
PLC Based

Frequency
60 Hz

Operating Temperature
Ambient

Noise Level
85 dB

Frame Type
Robust Welded Frame

Lubricating System
Centralized Manual

Cooling System
Air Cooled

Power Rating
30 hp total

Features
Double Door, Y-Type Hanger

Voltage
230V

Drive
Direct

Motor Power
7.5 hp each

Production Capacity
15 ton/day

Accuracy
High Cleaning Efficiency

Connectivity Options
No digital connectivity

Machine Type
Automatic Hanger Type

Product Type
Hanger Type Shot Blasting Machine

Technology
Wheel Blasting

Power Source
Electric

Operating Type
Automatic

Power
7.5 hp x 4 wheels

Weight (kg)
2500 Kg Approx.

Color
Industrial Blue/Grey

Usage & Applications
Fabrication, Beam Blasting

Hanger Type
Y Type

Application Scope
Beam & Steel Structure

Number of Wheels
4

Power Phase
Three Phase

Max Load Capacity
500 kg/hanger

Material Processed
Steel, Fabrication Parts

Cycles per Hour
6-8

Door Type
Double Door Front Loading

Safety Features
Interlocked Doors

Dust Collection
Bag Filter Integrated

Blast Wheel Brand
Rotofinish

Hanger Type Shot Blasting Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
2-10 Days

Main Domestic Market
All India

About Hanger Type Shot Blasting Machine

Experience the ephemeral advantage of our Hanger Type Shot Blasting Machine - a terrific, gilt-edged solution designed for rapid, high-volume steel and fabrication cleaning. Featuring a towering max load capacity of 500 kg per Y-type hanger and powered by four robust 7.5 hp Rotofinish wheels, this automated marvel ensures high efficiency and consistent results. The limited-time, instant checkout offer includes a double-door front-loading system, interlocked safety doors, and a bag filter dust collection for optimal safety. Perfect for beam and structural cleaning, this PLC-controlled, three-phase machine is engineered for demanding industrial settings, delivering 15 tons daily with exceptional precision and reliability.

Premium Features and Application Versatility

The Hanger Type Shot Blasting Machine stands out with its air-cooled system, centralized manual lubrication, and robust welded frame. Parked in the industrial blue/grey palette, it delivers superior cleaning for beams, steel structures, and fabrication parts. Direct drive wheels and interlocked safety doors promote operator well-being, while high blasting accuracy ensures minimal rework. With usage in diverse fabrication and beam blasting projects, it delivers a towering blend of productivity, reliability, and long-term investment advantage.

Sample Policy, Certifications, and Supply Ability

Our sample policy ensures timely order completion and transparent inspection before shipment. The unit comes with vital certifications, assuring heightened quality standards for every machine dispatched. With a gilt-edged track record, our towering supply ability ensures prompt shipment with competitive rates, ready to meet your growing fabrication and structural project demands. Orders are processed efficiently to keep your production line seamless and up to industry benchmarks.

FAQ's of Hanger Type Shot Blasting Machine:

Q: How does the Y-type hanger design benefit my blasting operations?

A: The Y-type hanger accommodates a broad range of steel structures and fabrication parts, making loading easy and optimizing blasting coverage for superior cleaning performance.

Q: What safety features are included in this shot blasting machine?

A: This model comes with interlocked double doors, preventing operation when doors are open to ensure maximum operator safety during loading, blasting, and unloading.

Q: What materials and parts can be processed using this machine?

A: Designed for beams, steel structures, and various fabrication components, this machine efficiently removes scale, rust, and contaminants from a variety of steel parts.

Q: What is the expected cleaning efficiency and cycle rate?

A: The machine achieves high cleaning efficiency, processing 6-8 cycles per hour, equivalent to a production capacity of up to 15 tons daily.

Q: Where can I get details on pricing and model specifications?

A: Refer to the Rotofinish catalogue or contact us to receive tailored model details, rates, and specifications according to your operational needs.

Q: What are the power and utility requirements for installation?

A: The machine operates on a three-phase electric supply at 230V, 60 Hz, with a total power rating of 30 hp for its four blast wheels; no digital connectivity is required.
